Select the Right Corrugated Metal Hose: Length
To calculate the proper length of a hose assembly:
-
Verify that the installation is properly designed
You can see our illustration of the right and wrong ways to install a hose assembly. Basically, there are three considerations:
- Do not torque the hose.
- Do not overbend the hose.
- Do not compress the hose.
-
Calculate the live length of the assembly
The live length of the assembly is the amount of active (flexible) hose in an assembly; that is, the hose between the braid collars. See the Length Calculation chart for more information.
-
Calculate the overall length of an assembly
Overall length is equal to the live length plus the lengths of the braid collars and fittings. When adding fitting lengths be aware that the points from which measurements should be taken vary for different fitting types. When calculating overall length for assemblies with threaded fittings, remember to account for the length of thread that is lost by threading into the mating connection. See the Thread Allowance chart for more information.
-
JIC/SAE type fittings are measured from the seat of the fitting.
-
Elbows and other fittings with a radius are measured from the centerline of the fitting.
-
Flanges are measured from the flange face or from the face of the stub end if one is used.
-
Threaded fittings are measured to the end of the fitting.
